Digital Multimeter UNI-T UT33C+ Palm Size DMM
Availability:
10 in stock
₨3,000.00
10 in stock
Special Functions Of UT 33C PLUS Digital Multimeter:
- Diode
- Continuity Buzzer
- Data Hold
- Display Backlight
- Low Battery Display
- Input Impedance for DC
- Voltage Measurement: Around 10MW
- Max. Display: 1999
Features of UNI-T UT33C+ DMM:
- Functions:
- AC/DC voltage and DC current
- resistance
- temperature (ºC and ºF)
- diode test
- continuity test (with buzzer)
- Manual range selection
- Data Hold function
- Test probe holder
- Backlit LCD
- Auto power off
- Auto backlight off
Technical Specifications of UT 33C
| Function | Range | Accuracy |
|---|---|---|
| DC voltage | 200 mV/2 V/20 V/200 V/600 V | ±(0.5%＋2) |
| AC voltage | 200 V/600 V | ±(1.2%+3) |
| DC current | 2000 μA/20 mA/200 mA/10 A | ±(1%+2) |
| Resistance | 200 Ω/2 kΩ/20 kΩ/200 kΩ/20 MΩ | ±(0.8%+2) |
| Temperature | -40℃~1000℃ | ±(1%+4) |
| -40℉~1832℉ | ±(1.5%+5) | |
| General Specifications | ||
| Display | LCD, 2000 count | |
| Power | 1.5V battery (R03) × 2 pcs. | |
| Drop test | 2 m | |
| Dimensions | 134 mm × 77 mm × 47 mm | |
| Weight | 206 g (with batteries) | |
